Amorphous Powder Core HLM50 Series

HLM50 series have low loss, high magnetic flux density, and high reliability using our uniquely processed amorphous powder. This series is suited to coils for higher switching(100-200kHz) power electronics applications.

Product Catalog Download

Click here to download the product catalog


Contact

Soft Magnetic Materials and Components (for Ferrite Applied Product)

Features

Low loss amorphous powder core suitable for high efficiency power converter.

  1. 1High Saturation Flux Density Bs
    Higher saturation flux density compared to Sendust powder core.
  2. 2Low Core Loss
    Lower core loss than Sendust powder core.
  3. 3Suitable for PFC Circuit and Boost/Buck Converter
  4. 4Three Types of Core are in our Production Lineup
    Bare core, cased core and coated core can be applied depending on customer application.

DC Superposition Characteristics of Incremental Permeability

DC Superposition Characteristics of Incremental Permeability

Frequency characteristics of iron loss

Frequency characteristics of iron loss

Application

Power factor improving reactor for on-board chargers, air conditioners, UPS, power conditioners, etc.
Normal mode choke coil for EMI countermeasures.
Smoothing choke coil.
